Innomotics GM150 通用中压变频器
通用中压驱动器解决方案
A drive that adapts to your needs.
Need a versatile, high-performance solution for single- and multi-motor applications - whether you’re working with variable or constant torque?
Count on the GM150:
- for reliable performance
- flexible cooling
- quiet operation
- across a wide power range
Whether you install it indoors or outdoors.
Built with advanced IGBT and IGCT technologies, it ensures smooth operation – even under challenging load conditions. And with intuitive tools like the Drive Technology Configurator* and STARTER*, you streamline integration and speed up commissioning. Customize your setup with a wide range of components to meet your exact needs.
So keep your processes running smoothly and with a small footprint.
Engineer with precision. Your benefits.
Technical overview
| Output voltage range | 2.3 - 6.6 kV |
| Power range | 1 - 21 MVA |
| Cooling | Air, water |
| Max. output frequency | 250 Hz (induction motors) |
| Open / closed loop control | Fiber optic cable, isolating transformer (open and closed-loop control) Vector control (closed-loop control) |
| Degree of protection | According to IEC 60529: Standard: IP22 (air cooling), IP43 (water cooling) Optional: IP42 (air cooling), IP54 (water cooling) |
Save costs and space. In all kinds of industries and applications.
As a general purpose drive, you can deploy the GM150 for single and multi-motor applications with variable and constant torque characteristics in every mayor industry: In pumps and fans, compressors, conveyors, winders, extruders and mixers as well as mills. It is also available with marine and internal arc flash certifications.
中国张家港 PDH 工厂
配有Innomotics GL150 和 GM150 的Innomotics HV
- Oriental Energy Company Ltd.，中国张家港 PDH 工厂的三列压缩机。
EQUINOR，HAMMERFEST，挪威
Equinor 的 Hammerfest LNG Plant
- Equinor 的 LNG 设施将 Barents Sea 的天然气冷却至零下 160 摄氏度，将其填满特殊储罐，并将其输送到世界各地的港口。除此之外，它还特别依赖 Innomotics 的数字化工具来完成这项工作。
KRAFTWERK LAUSWARD，杜塞尔多夫，德国
Kraftwerk Lausward
- 杜塞尔多夫的目标是到 2050 年实现气候中和。他们计划建造这个联合循环发电厂，将杜塞尔多夫的能源转型提升到新的水平，该厂使用非常清洁的燃料以及来自西门子大型驱动应用事业部（现为 Innomotics）的电机和驱动器。
Success Stories
Reduce downtime with Inspire IQ and proactive services.
Maximize the potential of your GM150 with our condition monitoring software Inspire IQ. Or explore our full-service portfolio from consulting, service agreements and digital services to retrofits and upgrades.
